7kW
Single phase, 32A
About 35 to 45km/hour
Most Perth homes
11kW and 22kW three-phase charging
3 phase EV charger installation in Perth
A three-phase wallbox can deliver up to 22kW. Most cars will take 11kW. A smaller group can use the full output. We design around the car and the switchboard, not the number printed on the box.
The number that matters
The charger rating is not the charging speed
A 22kW wallbox is the electrical ceiling. The car's onboard AC charger controls the actual draw. Connect an 11kW EV and it takes 11kW. Connect a 7kW EV and it takes about 7kW. Nothing is forced into the battery.
11kW
Three phase, 16A
About 55 to 70km/hour
Most three-phase EVs
22kW
Three phase, 32A
About 110 to 130km/hour
Cars with 22kW onboard AC
Before installation
Four checks decide whether 22kW works
Supply
We confirm genuine three-phase supply and the main switch rating, not just a three-phase-looking meter.
Capacity
Ducted aircon, pool equipment, induction cooking and electric hot water all count toward available capacity.
Cable route
A three-phase circuit uses a larger cable. Distance, roof access, paving and the mounting position move the installation cost.
Protection
The charger needs a dedicated circuit, compliant isolation and the correct AC and DC leakage protection for its design.
Vehicle limits
Which cars use three phase?
Common 11kW cars
- Tesla Model 3 and Model Y
- BYD Seal
- Kia EV5, EV6 and EV9
- Hyundai Ioniq 5 and Ioniq 6
- Volvo and Volkswagen EVs
Cars that may accept 22kW
- Renault Megane E-Tech
- Polestar 4
- Selected Porsche Taycan variants
- Selected Audi e-tron GT variants
- Some European models with optional 22kW AC
Variant and option packs matter. We check the exact vehicle specification before promising a speed.
Solar on three phases
Fast when needed. Solar-aware when parked.
A Zappi 22kW or Fronius Wattpilot can reduce output to follow available solar rather than drawing the maximum all day. Three current sensors measure what each phase is doing. Load management then protects the main supply when the home is busy.
Solar diversion and grid scheduling in one unit
The right hardware
Three-phase chargers we recommend
myenergi Zappi 22kW is the solar-diverting benchmark. Fronius Wattpilot is the natural fit for a Fronius solar system. Tesla Wall Connector is a clean choice for simple charging and multi-unit load sharing. We choose around the electrical system, not a preferred badge.
Three-phase FAQ
22kW home charging questions, answered
Do I need three-phase power for an EV charger?+
Not for a normal 7kW home charger. You only need three phase when you want 11kW or 22kW AC charging, or when the home's load is better spread across three phases. Most Perth drivers can comfortably recharge overnight on single phase.
Can I install a three-phase EV charger at home?+
Yes, provided the property already has three-phase supply or the supply is upgraded first. We check the main switch, meter, switchboard capacity, cable route and the car's AC limit before specifying the circuit and charger.
How fast is a 22kW EV charger?+
A car that accepts the full 22kW can add roughly 110 to 130km of range per hour. Most Australian EVs accept only 11kW AC, so the same 22kW wallbox will add closer to 55 to 70km per hour when connected to them.
How long does a 22kW EV charger take?+
A 77kWh battery takes about three and a half to four hours from empty if the car accepts the full 22kW. If that car is limited to 11kW, allow about seven hours. Charging losses, temperature and battery management can add a little time.
What is the difference between a 7kW and 22kW EV charger?+
A 7kW charger uses one phase at 32 amps. A 22kW charger uses all three phases at 32 amps per phase. The 22kW unit has three times the electrical capacity, but the car's onboard charger decides whether it receives 7kW, 11kW or the full 22kW.
How do I know if my Perth home has three-phase power?+
The quickest check is the main switch or incoming supply at the switchboard. Three linked main switches or three incoming active conductors normally indicate three phase. Send us clear photos of the meter and switchboard and our team can confirm it before a visit.
Can a 22kW charger use rooftop solar?+
Yes, with a solar-aware unit and metering across all three phases. A Zappi 22kW or Fronius Wattpilot can follow available surplus rather than drawing the full 22kW. The result depends on inverter size, export across each phase and household load.
Perth service area
Where we install across Perth
We are a Perth based electrical contractor working the full metro, from Yanchep in the north to Mandurah in the south. Most jobs are booked within three to seven days of you accepting the quote.
